Запчасти для колесных экскаваторов Hyundai R170W-7 PILOT HYD PIPING(BASE 2, 2-BLOCK, OPT)
| № | Номер | Описание | Заказать |
|---|---|---|---|
| 3 | 31E3-0017 | FILTER-LINE | |
| 3-2 | 31E3-0018 | ELEMENT-LINE FILTER | |
| 4 | 31E3-3187 | ACCUMULATOR | |
| 6 | X500-110001 | CONNECTOR-ORFS | |
| 9 | 31N6-24200 | CONNECTOR | |
| 10 | X520-110001 | ELBOW-90,ORFS | |
| 11 | X520-110002 | ELBOW-90,ORFS | |
| 12 | X520-110003 | ELBOW-90,ORFS | |
| 17 | 31N6-22400 | ADAPTOR | |
| 19 | X820-045151 | TEE-R/TYPE,ORFS | |
| 23 | 31EK-11130 | COUPLING-SCREW | |
| 28 | X500-110003 | CONNECTOR-ORFS | |
| 30 | X520-110004 | ELBOW-90,ORFS | |
| 34 | X820-125452 | TEE-R/TYPE,ORFS | |
| 35 | S035-082546 | BOLT-W/WASHER | |
| 41 | S621-014001 | O-RING | |
| 42 | S621-018001 | O-RING | |
| 44 | S631-011004 | O-RING | |
| 45 | S631-014004 | O-RING | |
| 46 | S631-018004 | O-RING | |
| 47 | S631-024004 | O-RING | |
| 51 | P930-122013 | HOSE ASSY-ORFS 0X90 | |
| 52 | P930-122012 | HOSE ASSY-ORFS 0X90 | |
| 59 | X420-042007 | HOSE ASSY-SYNFLEX,ORFS | |
| 60 | X420-042009 | HOSE ASSY-ORFS 0X90 | |
| 60 | X420-042009 | HOSE ASSY-ORFS 0X90 | |
| 72 | P930-062009 | HOSE ASSY-ORFS 0X90 | |
| 73 | P910-082018 | HOSE ASSY-ORFS 0X0 | |
| 80 | S621-011001 | O-RING |
