Запчасти для гусеничных экскаваторов Hyundai R360LC-7A UPPER HYD PIPING(ATTACH, MCV TYPE 3)
| № | Номер | Описание | Заказать |
|---|---|---|---|
| 1 | 31NA-14310 | HOSE ASSY | |
| 1 | 31NA-14311 | HOSE ASSY | |
| 2 | 31NA-14320 | HOSE ASSY | |
| 2 | 31NA-14321 | HOSE ASSY | |
| 3 | 31NA-14331 | HOSE ASSY | |
| 4 | 31NA-14341 | HOSE ASSY | |
| 5 | 31NA-14351 | HOSE ASSY | |
| 6 | 31NA-14361 | HOSE ASSY | |
| 7 | 31NA-13101 | HOSE ASSY | |
| 7 | 31NA-13102 | HOSE ASSY-FLG(0X0) | |
| 8 | 31NA-12560 | PIPE WA-BOOM"LC" | |
| 9 | 31NA-12570 | PIPE WA-BOOM "SC" | |
| 10 | 31NA-13090 | BRACKET-BOOM PIPE | |
| 11 | 31EM-12170 | CLAMP-PIPE | |
| 12 | S017-100706 | BOLT-HEX | |
| 13 | S017-100856 | BOLT-HEX | |
| 14 | S037-103026 | BOLT-W/WASHER | |
| 15 | S109-100306 | BOLT-SOCKET | |
| 16 | S109-120406 | BOLT-SOCKET | |
| 17 | S205-10100B | NUT-HEX | |
| 18 | S411-100006 | WASHER-SPRING | |
| 19 | P173-160104 | FLANGE-HYD,SPLIT | |
| 20 | P174-200106 | FLANGE-SPLIT | |
| 21 | Y171-024004 | O-RING | |
| 22 | Y171-027004 | O-RING | |
| 23 | S621-021001 | O-RING | |
| 24 | S403-10100B | WASHER-PLAIN |
