Запчасти для колесных экскаваторов Hyundai R140W-7 QUICK CLAMP ASSY 3(#0429-)
| № | Номер | Описание | Заказать |
|---|---|---|---|
| * | 31N4-95810 | QUICK CLAMP ASSY-HOOK | |
| 1 | XKBN-00069 | BODY-HOOK TYPE | |
| 2 | XKBN-00070 | HITCH | |
| 3 | XKBN-00071 | CYLINDER ASSY | |
| 4 | XKBN-00072 | PIN-SAFETY | |
| 5 | XKBN-00105 | PIN-SNAP | |
| 6 | XKBN-00074 | PIN-HITCH | |
| 7 | XKBN-00075 | PIN-FRAME | |
| 8 | XKBN-00009 | NIPPLE-GREASE | |
| 9 | XKBN-00076 | PIN-CYLINDER | |
| 10 | XKBN-00077 | RING-SNAP | |
| 11 | XKBN-00078 | PIN-BRACKET | |
| 12 | XKBN-00199 | BOLT-HEX | |
| 13 | XKBN-00196 | NUT-HEX | |
| 14 | XKBN-00081 | HOSE-PROTECTOR | |
| 15 | XKBN-00016 | ELBOW-90 | |
| 17 | XKBN-00083 | WIRE ASSY | |
| 18 | XKBN-00084 | BOLT-HEX | |
| 19 | XKBN-00085 | WASHER-SPRING | |
| 20 | XKBN-00086 | LATCH WITH SPRING |
