Запчасти для колесных экскаваторов Hyundai R170W-9S UPPER HYD PIPING 1(ADJUST BOOM)
| № | Номер | Описание | Заказать |
|---|---|---|---|
| 1 | 31Q5-11190 | PIPE ASSY | |
| 6 | P930-128018 | HOSE ASSY-ORFS 0X90 | |
| 9 | P930-128020 | HOSE ASSY-ORFS 0X90 | |
| 11 | 31Q5-10310 | HOSE ASSY | |
| 12 | P910-042056 | HOSE ASSY-ORFS 0X0 | |
| 13 | P910-042062 | HOSE ASSY-ORFS 0X0 | |
| 14 | P910-042020 | HOSE ASSY-ORFS 0X0 | |
| 15 | 31N4-12270 | CLAMP-PIPE | |
| 16 | 31Q4-11170 | BRACKET | |
| 21 | X511-116544 | CONNECTOR-LONG,ORFS | |
| 26 | X511-112546 | CONNECTOR-LONG,ORFS | |
| 27 | X500-110001 | CONNECTOR-ORFS | |
| 28 | X520-110001 | ELBOW-90,ORFS | |
| 29 | X840-515151 | TEE-R/TYPE,ORFS | |
| 31 | S037-123026 | BOLT-W/WASHER | |
| 33 | S017-100256 | BOLT-HEX | |
| 34 | S017-100756 | BOLT-HEX | |
| 35 | S207-101002 | NUT-HEX | |
| 36 | S403-102002 | WASHER-PLAIN | |
| 37 | P173-120102 | FLANGE-HYD,SPLIT | |
| 38 | Y171-019004 | O-RING | |
| 39 | S109-100306 | BOLT-SOCKET | |
| 40 | S621-018001 | O-RING | |
| A | S621-014001 | O-RING | |
| B | S621-018001 | O-RING | |
| C | S621-011001 | O-RING | |
| D | S631-024004 | O-RING | |
| E | S631-029004 | O-RING | |
| F | S631-011001 | O-RING |
